Sanyo PLC-XM100 User Manual

83
ANALOG/ MONITOR OUT (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
1112
CONTROL PORT CONNECTOR (D-sub 9 pin)
-----
R X D
T X D
-----
SG
-----
RTS
CTS
Serial
1
2
3
4
5
6
7
8
DIGITAL DVI-D (DVI 24 PIN)
1
9
17
2
10
18
3
11
19
4
12
20
5
13
21
6
14
22
7
15
23
8
16
24
T.M.D.S. Data2–
No Connect
T.M.D.S. Data2+
No Connect
T.M.D.S. Data2 Shield
DDC Clock
DDC Data
No Connect
1
5
2
4
3
6
7
8
T.M.D.S. Data1–
No Connect
T.M.D.S. Data1+
No Connect
T.M.D.S. Data1 Shield
+5V Power
Ground (for +5V)
Hot Plug Detect
9
13
10
12
11
14
15
16
T.M.D.S. Data0–
No Connect
T.M.D.S. Data0+
No Connect
T.M.D.S. Data0 Shield
T.M.D.S. Clock Shield
T.M.D.S. Clock+
T.M.D.S. Clock–
17
21
18
20
19
22
23
24
Vcc
- Data
+ Data
Ground
1
2
3
4
USB CONNECTOR (Series B)
2
34
1
Appendix
-----
9
Red Input
Ground (Horiz.sync.)
Green Input
No Connect
Blue Input
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
Horiz. sync. Input (Composite H/V sync.)
Ground (Vert.sync.)
DDC Data
Ground
Vert. sync. Input
DDC Clock
9
13
10
12
11
14
15
+5V Power
Red Output
Ground (Horiz.sync.)
Green Output
No Connect
Blue Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
Horiz. sync. Output
Ground (Vert.sync.)
No Connect
No Connect
Vert. sync. Output
No Connect
9
13
10
12
11
14
15
No Connect
Input
Output
Configurations of Terminals
RX –
TX +
TX –
RX +
2
3
4
87654321
5
6
7
8
1
LAN TERMINAL
-----
-----
----------

Sanyo PLC-XM100 Specifications

General

Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 100 kHz
Projection technology	LCD
Contrast ratio (typical)	1000:1
Projector native resolution	XGA (1024x768)
Aspect ratio	4:3
RS-232 ports	1
Dimensions (WxDxH)	497.8 x 375.9 x 165.1 mm
Lamp type	NSH
Lamp power	275 W
Light source type	Lamp
Focus	Manual
RMS rated power	7 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level	31 dB

Weight and Dimensions

Weight	9661.5 g
