11
Part Names and Functions
To ensure safe operation, please observe the following
precautions :
– Do not bend, drop the remote control or expose the
remote control to moisture or heat.
– For cleaning, use soft dry cloth. Do not apply benzene,
thinner, splay or any chemical material.
t
e
!0
i
!4
r
!5
!3
q POWER ON-OFF button
Turn the projector on or off. (p18, 19)
w VIDEO button
Select VIDEO input source. (p23, 34)
e COMPUTER button
Select COMPUTER input source. (p23, 25, 35)
r MENU button
Open or close the On-Screen Menu. (p20)
i PAGE ed buttons
Scroll back and forth pages on the screen when giving a
presentation. Connect the projector and your computer
with a USB cable to use these buttons. (p9, 15)
!1
u D.ZOOM ed buttons
Zoom in and out the images. (p24, 33)
!5 AUTO PC button
Automatically adjust the computer image to its optimum setting.
(p24, 27)
!4 IMAGE button
Select the image level. (p24, 30, 37)
o FREEZE button
Freeze the picture. (p23)
!2
MUTE button
Mute the sound. (p 23)
!3
P-TIMER button
Operate the P-timer function. (p24)
!0
NO SHOW button
Temporarily turn off the image on the screen. (p24)
!6
KEYSTONE button
Correct the keystone distortion. (p22, 41)
t Point ed 7 8 ( VOLUME
+ / –
)
buttons
– Select an item or adjust the value in the On-Screen Menu. (p20)
– Pan the image in Digital zoom + mode. (p33)
– Adjust the volume level. (Point 7 8 buttons) (p23)
y SELECT button
– Execute the selected item. (p20)
– Expand or compress the image in Digital zoom mode. (p33)
qw
Remote Control
y
u
o
!6
!2
!1 LAMP CONTROL button
Select the lamp mode. (p24, 45)
Part Names and Functions
