22
Basic Operation
Rotate the Zoom Ring to zoom in and out.
Rotate the Focus Ring to adjust the projected picture focus.
Zoom Ring
(Rear)
Focus Ring
(Front)
• The arrows are white when there is no correction.
• The direction of the arrow being corrected turns red.
• The arrows disappear at the maximum correction.
• If you press the KEYSTONE button on the top control
or on the remote control once more while the
keystone dialog box is being displayed, the keystone
adjustment will be canceled.
If a projected picture has keystone distortion, correct the
image with Keystone adjustment.
Press the KEYSTONE button on the top control or on the
remote control. The keystone dialog box will appear.
Correct keystone distortion by pressing the Point ed
buttons. Keystone adjustment can be memorized. (p41)
Reduce the upper width
with Point e button.
Reduce the lower width
with Point d button.
Keystone Correction
REMOTE CONTROL
TOP CONTROL
KEYSTONE
button
KEYSTONE button
To Next Page
