Mechanical disassemblies
2
Lamp cover ass'y removal.
1. Loosen the screw-A and remove the Lamp cover ass'y.
2. Remove the 2 screws-B(T3X8) and remove the shield plate.
A
Lamp cover ass'y
B
B
Shield plate
Lamp cover
