- 18 -
Mechanical disassemblies
3
Filter removal.
1. Remove the Filter cover and Filter.
4
AV panel removal.
1. Remove the 2 screws-A(M3x8), remove the screw-B(T3x8) and remove the AV panel.
Filter cover
Filter
B
A
AV panel
A
