- 20 -
Mechanical disassemblies
7
Cover lens top removal.
1. Remove the Cover lens top upward.
8
Cabinet front ass'y removal.
1. Remove the 2 screws (T3x8) and remove the Cabinet front ass'y forward.
Cabinet front ass'y
Cover lens top
