Page #91 background image
Electrical Parts List
MD4-Z200000
- 91 -
ASSMBLIED BOARDS
!
610 335 4170 ASSY,PWB,MAIN MD4A
!
610 335 4149 ASSY,PWB,R/C MD4A
!
610 335 4750 ASSY,PWB,FILTER MD4A
!
610 335 4651 ASSY,PWB,DOOR SWITCH1 MD4A
!
610 335 4699 ASSY,PWB,DOOR SWITCH2 MD4A
!
610 335 4668 ASSY,PWB,LAMP SWITCH MD4A
OUT OF CIRCUIT BOARD
L901 945 003 3811 CORE,FERRITE
945 040 2594 CORE,FERRITE
L902 945 003 3835 CORE,FERRITE
!
LP901 610 336 5404 COMPL,OPTICAL LMP-MD4A
ZCN101 945 003 3835 CORE,FERRITE
!
A901 645 093 7811 UNIT,BALLAST
!
A902 645 093 7828 UNIT,POWER
!
BLST&LMP 610 336 0157 CABLE,BALLAST MD4A
!
FN901 645 094 2709 MOTOR,FAN DC 1.2W
!
FN902 645 094 2686 MOTOR,BLW DC 4.14W
!
FN903 645 094 2716 MOTOR,FAN DC 1.1W
!
FN904 645 094 2693 MOTOR,BLW DC 4.14W
!
FN905 645 094 2723 MOTOR,BLW DC 6.7W
!
SW902 945 048 3159 SWITCH,THERMAL(100DEG)
TH901 945 079 7768 SWITCH,THERMAL,THERMISTOR
TH902 945 079 7775 SWITCH,THERMAL,THERMISTOR
WK8J 610 337 2211 HALOGEN FREE WIRE 4P 1.5MM
WK8L 610 337 2198 HALOGEN FREE WIRE 3P 1.5MM BLU
WK8M 610 337 2181 HALOGEN FREE WIRE 3P 1.5MM RED
WK8P 610 337 2174 HALOGEN FREE WIRE 5P 1.5MM
WK8Q 610 337 2204 HALOGEN FREE WIRE 5P 1.5MM
610 335 4170 ASSY,PWB,MAIN MD4A
TRANSISTOR
Q1001 305 217 8614 TR RN1105 TE85L
Q1002 305 217 8614 TR RN1105 TE85L
Q1021 305 217 8614 TR RN1105 TE85L
Q1022 305 217 8614 TR RN1105 TE85L
Q1051 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1052 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1053 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1231 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1243 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q1244 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q2853 305 217 7518 TR RN1102 TE85L
Q2854 305 217 7518 TR RN1102 TE85L
Q2856 305 217 7518 TR RN1102 TE85L
Q2857 305 217 7518 TR RN1102 TE85L
Q3001 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3002 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3003 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3004 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3006 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3007 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q3801 305 191 5814 TR 3LN01C-TB-E
Q4001 305 014 4512 TR 2SC2412K T146 R
Key. No. Part No. Description Key. No. Part No. Description
