7. EXPLANATION OF PARAMETERS
7－42
Mode Page
Abbre-
viation
Name and description
Standard
value
Unit
Setting
range
Remarks
1 16 MENP Motor encoder pulse number
• Sets the number of pulses of the encoder
used.
• The following shows the number of encoder
pulse in standard combination:
Saved wiring incremental encoder
--- 2000 P/R.
Absolute encoder --- 2048 P/R.
$$$$ P/R 500 to
65535
( 1)
( 2)
17 EENP Number of pulses of fully closed encoder
• Sets the number of pulses of the encoder
used in terms of the motor shaft.
• This parameter is usable only on the servo
system that supports the fully closed design.
$$$$ P/R 500 to
65535
( 1)
( 2)
18 OLWL Over load warning level
• This parameter is for warning output before
getting into over load alarm status and motor
stoppage (see 9.6 warning output for over
load warning output function).
• Possible setting level range is from 30 to 99%
when over load alarm level is regarded as
100%. There will be no over load warning
output in setting 100%.
100 % 30 to
100
( 2)
1 When changing your setting, set Func6 bit7 to "1" from Screen Mode 2 prior to the
change.
2 Turn the control power off once before the change.
