42
Example
Determine an unknown percentage; save active weight value
as a reference percentage
Configuration (changes in the factory settings required for this example):
Menu path: Application > Weighing in percent (2 1 5)
Menu path: Reference percentage > 100 % (3 3 5)
Step Key (or instruction) Display/Output
1. Turn on the scale e
2. Zero the scale, if necessary ( 0.000 kg
3. Place the reference weight + 2.295 kg
(100 %) on the scale
(in this case, 2.295 kg)
4. Start application v + 100.00 %
If the printout is configured to
to include data ID codes, the
data is printed as shown here Wxx% + 2.295 kg
5. Display weight w + 2.295 kg
6. Display percentage w + 100.00 %
7. Display reference percentage v ref100
> 2 seconds
8. Place a sample of unknown + 140.41 %
weight on the scale (in this
case, 3.225 kg)
9. Print percentage p Prc + 140.41 %
10. Unload the scale 0.00 %
11. To continue weighing,
repeat the procedure,
starting from Step 8.
