48
Example
Total weight values
Configuration (changes in the factory settings required for this example):
Menu path: Application > Totalizing (2 1 8)
Step Key (or instruction) Display/Output
1. Turn on the scale e
2. Zero the scale, if necessary ( 0.000 kg
3. Place sample on scale + 0.380 kg
(in this case, 380 g)
4. Save weight value v + 0.380 kg
1
If the printout is configured to
to include data ID codes, the
data is printed as shown here G + 0.380 kg
5. Place next sample on scale + 0.575 kg
1
(in this case, 575 g)
6. Save value in totalizing memory v + 0.575 kg
2
7. View value in totalizing memory v 0.955 kg
2
(briefly)
(value also printed when you > 2 seconds
select this function) Sum + 0.955 kg
8. Clear totalizing memory and c Sum + 0.955 kg
print sum
9. To continue totalizing,
repeat the procedure starting
from Step 4.
