SARTORIUS Portable and Gold
33
Data Output Format
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ Z Z Z Z Z Z g _ _
_ _ _ _ _ _ _ _ _ _ _ k g _ CR LF
î . . . . o z t
1st character Plus or minus sign or space
2nd to 4th characters Space
5th to 10th characters Digit, space or decimal point
11th character Space
12th to 14th characters Letter or space
15th character Carriage return
16th character Line feed
Data Output Parameters
Codes 8 - 1 to 8 - 4
You can program the balance/scale for data output on the basis of the stability status of the weighing system.
You can choose to have data output only at stability or regardless of stability.
If you opt to have data output only once the weighing system has stabilized, an output command will remain stored
until the system has stabilized.
In the auto print setting, data output is continuous. If you have additionally selected the stability parameter for this
option, data will be output only once the stability symbol is indicated in the display. The data output command is
activated the moment you turn on the power. You can stop the automatic data output, and start it again, by pressing
the print key.
Data Output and Pin Assignment
Each signal received by the RxD line will initiate data output.
Female Interface Connector
25-position D submini, DB25S with screw lock for cable gland
Male Connector Required
25-pin D submini, DB25S with shielded cable clamp assembly (Amp typ 826 982 - 1) and fastening screws (mate
screws for female screw lock, Amp type 164 868 -1)
