Service Manual Signum
Description of the Equipment
The Sartorius Signum series advanced scale (SIWA) with a mechatronic weighing system
Overview of the Signum Series Scale Featuring Strain Gauge Technology
A Power supply
B Data output (various interfaces
can be installed as optional
equipment)
C Main PCB
D Strain gauge technology
– system PCB
E Various versions of the strain
gauge system
F Standard housing
G Without built-in motorized
internal calibration weight
* This cable is suitable only for the
Ethernet and Profibus options
A
B
C
System cable Cable to main PCB
D
Cable to power supply Data output cable * Cable to the system PCB
Standard data output PCB
G
E
F
A
C
B
Cable to Standard data output PCB
