Service Manual Signum
Calibration/Adjustment Data
Calibration/Adjustment Data for the SIWA
Example for the order number of a Signum full range scale: SIWADCP-2-35-S
Model type | Sensor | Platform | Type of/ | Application- | Capacity | Display | Verifiable/ |
technology dimensions material level (kg) resolution verified
(in mm) versions
SIW A
2)
DC P
4)
2 35 S
2)
= SIWA: „Advanced“ mechatronic weighing system (strain-gauge technology)
4)
= Painted
Signum SIWAEDG
SIWAEDG-3-65-S 65 kg 1 g 20 kg 1 g 20 kg 2 g
F2
20 kg 20 kg 1 g - kg 0 - Max kg 3 g 8 n
SIWAEDG-3-35-S 35 kg 0,5 g 10 kg 0,5 g 10 kg 2 g
F2
10 kg 10 kg 0,5 g - kg 0 - Max kg 1,5 g 6 n
SIWAEDG-3-16-S 16 kg 02 g 5kg 0,2 g 5kg 0,8 g
F2
5kg 5kg 0,2 g - kg 0 - Max kg 0,6 g 6 n
