Data Output Format
Each line in a print job can contain up to 22 characters
(up to 20 printable characters plus two control characters). The
first 6 characters, called the “data header”, identify the subsequent
value. You can suppress the header under menu item 7.2 in the
“Printouts” menu; in this case, the print job has up to 16 characters
(up to 14 printable characters plus two control characters).
Examples:
+ 235 pcs without header
Qnt + 235 pcs With header
Display segments that are not activated are output as spaces.
Values with no decimal point are output without a decimal point.
Data Output Format with 16 Characters (without Data Header)
Normal Operation:
Pos. 12345678910111213141516
+ *DDDDDDDD * UUUCRLF
or – * DDDDDDDD *UUUCRLF
or **************CRLF
+–: Plus or minus sign
*: Space
A: Digit or letter (max. 7 characters plus decimal point)
U: Unit symbol (1 to 3 letters, followed by 0 to 2 spaces)
CR: Carriage return
LF: Line feed
Special Codes:
Pos. 12345678910111213141516
******––******CRLF
or ******H*******CRLF
or ******HH******CRLF
or ******L*******CRLF
or ******LL******CRLF
or ******C*******CRLF
*: Space
– –: Final readout mode
H: Overload
HH: Overload in Checkweighing
L: Underload
LL: Underload in Checkweighing
C: Calibration/adjustment
Error Codes:
Pos. 12345678910111213141516
***Err**##****CRLF
or ***Err*###****CRLF
*: Space
#: Error code number (2 or 3 digits)
Example (output of value: +1255.7 g):
Pos. 12345678910111213141516
+* * *1255. 7*g**CRLF
Position 1: Plus or minus sign or space
Position 2: Space
Positions 3–10: Weight value with decimal point;
leading zeros are output as spaces.
Position 11: Space
Positions 12–14: Unit symbol or space
Position 15: Carriage return
Position 16: Line feed
Data Output Format with 22 Characters (with Data Header)
Normal Operation:
Pos. 12345678910111213141516171819202122
IIIIII+*DDDDDDDD *UUUCRLF
or IIIIII–*DDDDDDDD * UUUCRLF
or ********************CRLF
K: ID code character, right-justified with spaces
+-: Plus or minus sign
*: Space
A: Digit or letter (max. 7 characters plus decimal point)
U: Unit symbol (1 to 3 letters, followed by 0 to 2 spaces)
CR: Carriage return
LF: Line feed
Special Codes:
Pos. 12345678910111213141516171819202122
Stat********––******CRLF
or Stat********H*******CRLF
or Stat********HH******CRLF
or Stat********L*******CRLF
or Stat********LL******CRLF
or Stat********C*******CRLF
*: Space
– –: Final readout mode
H: Overload
HH: Overload in Checkweighing
L: Underload
LL: Underload in Checkweighing
C: Calibration/adjustment
Interface Port
