Sartorius Signum 3 Operating Instruction

83
For COM1 (25-pin D-Sub female connector)
COM1 All Signum models Signum 2 and 3 only
Standard: RS-232 Computer with serial RS-232 input port Red-green-red display
SBI/XBPI protocol YRD14Z (uses digital control lines)
Printers: Digital control lines
YDP04IS (TTL/ 5V)
YDP02IS <;=;set;>
YDP12IS to relay box YSB01
YDP20-0CE
External Alibi memory: YAM01IS Additional digital platform with
RS-232 interface
External Bluetooth adapter: YBT01 Additional weighing instrument with
SMA/XBPI protocol
Second display: YRD02Z
USB adapter cable for connecting
a computer over USB: YCC01IS
Digital in (TTL/ 5V)
Option A31: “clock” As with the standard RS-232 interface, but includes date/time
RS-232 connector
Universal in: print/ tare Print/tare key function
For UniCOM
Male connector:
for RS-232/ RS-422/ RS-485 analog output port/ digital I/O: 25-pin D-Sub female connector
Ethernet: RJ45 socket
Profibus: D-Sub 9 female connector
UniCOM (can be selected optionally)
RS-232 Option A1, YDO01SW-232 – Computer with serial RS-232 input port, SBI/XBPI protocol
– External Alibi memory: YAM01IS
– External Bluetooth adapter: YBT01
– Second display: YRD02Z
– USB adapter cable for connecting a computer over USB: YCC01-USBM2
– Second weighing point: scale with RS-232 data output
– Second weighing point: IS platform with optional RS-232 data output
– Second weighing point for analog platform (e.g., Combics CAP.. platform)
over YCO02IS-0CE transmitter
RS-422 Option A25, YDO01SW-485/422 Point-to-point connection with SBI/XBPI or SMA protocol
RS-485 Option A3, YDO01SW-485/422 Network, up to 32 weighing instruments over XBPI bus
Additional IS platform with standard RS-485 data output
Analog output port option A9, YDO01SW-A0 Controllers with analog input
Dig. 5 In/5 OUT: Option A5, YDO01SW-DIO For connecting the Signum scale to controllers
Digital IN: Voltage: 0-30V DC; current: 1 to 2 mA
Digital OUT: Voltage: >30V DC; current: 100 mA
For specific signals, please refer to the detailed descriptions of the options
Ethernet: Option B9, YDO01SW-ETH Office or production area network
Profibus: Option B1, YDO01SW-DP Connect devices over Profibus DP field bus
* For model SIWSDCS with a round connector, you will need a corresponding adapter cable.
Contact your Sartorius dealer for more information.
Interface Port
