Intended Use
Intended Use
Signum
®
1, 2 and 3 are precise and
rugged complete scales that give you
reliable weighing results.
The Signum
®
series of compact scales
includes models with strain-gauge
weighing systems as well as versions
equipped with monolithic technology,
using the principle of electromagnetic
force compensation.
These compact industrial scales offer
the following special features:
– Rugged and durable Sartorius quality
– Flexible options for display unit
installation
– Wide range of configuration options
for customized operation
– Variety of optional data interfaces
– Optional IP65 protection from dust
and jets of water (standard for the
SIWSDCS/SIWSBBS/SIWAEDG series)
– Optional versions for use in zone 2 and
22 hazardous areas
– High quality workmanship and materials
– Choice of application levels
– Available in weighing capacities
between 3 and 35 or 60 kg; choice of
resolutions available for each capacity
– Various interface options
– Verifiable models in accuracy classes
K (SIWS...) and class l (SIWR)
– Option for use in hazardous areas zones
2, 22
– Preload values can be defined (for
equipment installed on the scale)
– Display can be decoupled from the
weighing technology
Additional features include:
– Large keys with positive click action
– Numeric and alphabetic input
– Large backlit 14-segment display
– Connectivity for two weighing
platforms (digital platform or, using
an optional A/D converter, analog
platform)
Advantages in routine weighing tasks:
– Fast response times
– Independence from location of platform
installation
– Designation of weight values with up to
4 lines of alphanumeric text
– Flexibility afforded by diversity of
interfaces
– Security through password protection
Range of Models
Three different type of weighing
technology are used in the Signum
®
series, offering different performance
levels:
Signum
®
Regular
SIWRDCP Models
– Standard weighing system
– Resolutions up to 35,000d.
– Models verified at the factory for use in
legal metrology, Class l:
2 x 3000/3500e (dual range);
1 x 6000/7500e and
1 x 3000e (single range)
– The single-range scales with variable
scale intervals are available with your
choice of a fixed or adjustable fine
range
Signum
®
Advanced
SIWADCP/SIWAEDG models:
– Mechatronic weighing system
– Resolutions up to 80,000d
SIWABBP models:
– Mechatronic weighing system
– Resolutions up to 150,000d.
Signum
®
Supreme
SIWSDCP models:
– Monolithic Weighing System
– Resolutions up to 350,000d.
SIWSBBP models:
– Monolithic Weighing System
– Resolutions up to 620,000d.
– Models verified at the factory for use
in legal metrology, Class K:
130,000e, 1+62,000e (e=d);
1+6000e, 31,000e,
35,000e, 61,000e
(single and dual range);
16,000e (single and dual range) each
with internal motorized calibration
weight
– The single-range scales with variable
scale intervals are available with your
choice of a fixed or adjustable fine
range
Signum
®
Supreme featuring
a stainless steel housing
SIWSDCS/SIWSBBS models:
– Monolithic Weighing System
– Resolutions up to 610,000d
– Models verified at the factory for use
in legal metrology, Class K:
1 x 30,000e (e=d); 1 x 6000e;
35,000e (single and dual range);
16,000e (single and dual range,
each with internal motorized
calibration weight)
– The single-range scales with variable
scale intervals are available with your
choice of a fixed or adjustable fine
range
Signum
®
Regular/Advanced/Supreme
are all available with application levels
1, 2 and 3.
Symbols
The following symbols are used in the
text:
§ Denotes general operating instructions
$ Indicates instructions for exceptional
cases
> Describes the outcome of an operating
step
! Indicates a hazard
Hotline
Phone: +49.40.67960444
Fax: +49.40.67960474
