Satec PM130P Reference Guide

16
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x161F Not used UINT32 R
0x1620 Not used UINT32 R
0x1621 Not used UINT32 R
0x1622 In Ampere demand 0-Imax U2 UINT32 R
Total Energies
E
0x1700
kWh import
0-999,999,999 kWh UINT32 R
0x1701 kWh export 0-999,999,999 kWh UINT32 R
0x1702 Not used INT32 R
0x1703 Not used UINT32 R
0x1704 kvarh import 0-999,999,999 kvarh UINT32 R
0x1705 kvarh export 0-999,999,999 kvarh UINT32 R
0x1706 Not used INT32 R
0x1707 Not used UINT32 R
0x1708 kVAh total 0-999,999,999 kVAh UINT32 R
0x1709 Not used UINT32 R
0x170A Not used UINT32 R
0x170B kVAh import 0-999,999,999 kVAh UINT32 R
0x170C kVAh export 0-999,999,999 kVAh UINT32 R
0x170D Not used UINT32 R
0x170E Not used UINT32 R
0x170F Not used UINT32 R
0x1710 Not used UINT32 R
0x1711 Not used UINT32 R
0x1712 kvarh Q1 0-999,999,999 kvarh UINT32 R
0x1713 kvarh Q2 0-999,999,999 kvarh UINT32 R
0x1714 kvarh Q3 0-999,999,999 kvarh UINT32 R
0x1715 kvarh Q4 0-999,999,999 kvarh UINT32 R
Phase Energies
E
0x1800
kWh import L1
0-999,999,999 kWh UINT32 R
0x1801
kWh import L2
0-999,999,999 kWh UINT32 R
0x1802
kWh import L3
0-999,999,999 kWh UINT32 R
0x1803 kvarh import L1 0-999,999,999 kvarh UINT32 R
0x1804 kvarh import L2 0-999,999,999 kvarh UINT32 R
0x1805 kvarh import L3 0-999,999,999 kvarh UINT32 R
0x1806 kVAh total L1 0-999,999,999 kVAh UINT32 R
0x1807 kVAh total L2 0-999,999,999 kVAh UINT32 R
0x1808 kVAh total L3 0-999,999,999 kVAh UINT32 R
V1/V12 Harmonic Distortions
EH 1
0x1900
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1901
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1927
H40 Harmonic distortion
0-10000 0.01% UINT16 R
Provided by Northeast Power Systems, Inc.
www.nepsi.com
