Point ID Description
Options/Range
2
Units
2
Type R/W Notes
1-Second Phase Values
0x1100 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
0x1101 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
0x1102 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
0x1103 I1 Current 0-Imax U2 UINT32 R
0x1104 I2 Current 0-Imax U2 UINT32 R
0x1105 I3 Current 0-Imax U2 UINT32 R
0x1106 kW L1 -Pmax-Pmax U3 INT32 R
0x1107 kW L2 -Pmax-Pmax U3 INT32 R
0x1108 kW L3 -Pmax-Pmax U3 INT32 R
0x1109 kvar L1 -Pmax-Pmax U3 INT32 R
0x110A kvar L2 -Pmax-Pmax U3 INT32 R
0x110B kvar L3 -Pmax-Pmax U3 INT32 R
0x110C kVA L1 0-Pmax U3 UINT32 R
0x110D kVA L2 0-Pmax U3 UINT32 R
0x110E kVA L3 0-Pmax U3 UINT32 R
0x110F Power factor L1 -1000-1000
×0.001
INT16 R
0x1110 Power factor L2 -1000-1000
×0.001
INT16 R
0x1111 Power factor L3 -1000-1000
×0.001
INT16 R
0x1112 V1/V12 Voltage THD 0-9999
×0.1%
UINT16 R
1
3-sec value
0x1113 V2/V23 Voltage THD 0-9999
×0.1%
UINT16 R
1
3-sec value
0x1114 V3/V31 Voltage THD 0-9999
×0.1%
UINT16 R
1
3-sec value
0x1115 I1 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
0x1116 I2 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
0x1117 I3 Current THD 0-9999
×0.1%
UINT16 R 3-sec value
0x1118 I1 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
0x1119 I2 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
0x111A I3 K-Factor 10-9999
×0.1
UINT16 R 3-sec value
0x111B I1 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
0x111C I2 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
0x111D I3 Current TDD 0-1000
×0.1%
UINT16 R 3-sec value
0x111E V12 Voltage 0-Vmax U1 UINT16 R
0x111F V23 Voltage 0-Vmax U1 UINT16 R
0x1120 V31 Voltage 0-Vmax U1 UINT16 R
1-Second Total Values
0x1400 Total kW -Pmax-Pmax U3 INT32 R
0x1401 Total kvar -Pmax-Pmax U3 INT32 R
0x1402 Total kVA 0-Pmax U3 UINT32 R
0x1403 Total PF -1000-1000
×0.001
INT16 R
0x1404 Total PF lag 0-1000
×0.001
UINT16 R
0x1405 Total PF lead 0-1000
×0.001
UINT16 R
0x1406 Total kW import 0-Pmax U3 UINT32 R
0x1407 Total kW export 0-Pmax U3 UINT32 R
