Satec PM130P Reference Guide

19
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT32 R
1
0x3703 I1 Maximum ampere demand 0-Imax U2 UINT32 R
0x3704 I2 Maximum ampere demand 0-Imax U2 UINT32 R
0x3705 I3 Maximum ampere demand 0-Imax U2 UINT32 R
0x3706 Not used UINT32 R
0x3707 Not used UINT32 R
0x3708 Not used UINT32 R
0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT32 R
0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT32 R
0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT32 R
0x3737 Not used UINT32 R
0x370D Not used UINT32 R
0x370E Not used UINT32 R
0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT32 R
0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT32 R
0x3711 Not used UINT32 R
0x3712 Not used UINT32 R
0x3713 Not used UINT32 R
0x3714 Not used UINT32 R
0x3715 In Maximum ampere demand 0-Imax U2 UINT32 R
V1/V12 Harmonic Angles
EH 1, 3
0x6400
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x6400
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6427
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
V2/V23 Harmonic Angles
EH 1, 3
0x6500
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x6500
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6527
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
V1/V31 Harmonic Angles
EH 1, 3
0x6600
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x6600
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6627
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I1 Harmonic Angles
EH 3
0x6700
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x6700
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6727
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I2 Harmonic Angles
EH 3
0x6800
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
Provided by Northeast Power Systems, Inc.
www.nepsi.com
