Satec PM130P Reference Guide

15
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x1408 Total kvar import 0-Pmax U3 UINT32 R
0x1409 Total kvar export 0-Pmax U3 UINT32 R
0x140A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
0x140B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
0x140C 3-phase average current 0-Imax U2 UINT32 R
1-Second Auxiliary Values
0x1500 Not used UINT32 R
0x1501 In (neutral) Current 0-Imax U2 UINT32 R
0x1502 Frequency 0-Fmax
×0.01Hz
UINT16 R
0x1503 Voltage unbalance 0-3000
×0.1%
UINT16 R
0x1504 Current unbalance 0-3000
×0.1%
UINT16 R
Present Volt, Ampere and Power Demands
0x1600 V1/V12 Volt demand 0-Vmax U1 UINT32 R
1
0x1601 V2/V23 Volt demand 0-Vmax U1 UINT32 R
1
0x1602 V3/V31 Volt demand 0-Vmax U1 UINT32 R
1
0x1603 I1 Ampere demand 0-Imax U2 UINT32 R
0x1604 I2 Ampere demand 0-Imax U2 UINT32 R
0x1605 I3 Ampere demand 0-Imax U2 UINT32 R
0x1606 kW import block demand 0-Pmax U3 UINT32 R
0x1607 kvar import block demand 0-Pmax U3 UINT32 R
0x1608 kVA block demand 0-Pmax U3 UINT32 R
0x1609 kW import sliding window demand 0-Pmax U3 UINT32 R
0x160A kvar import sliding window demand 0-Pmax U3 UINT32 R
0x160B kVA sliding window demand 0-Pmax U3 UINT32 R
0x160C Not used 0 UINT32 R
0x160D Not used 0 UINT32 R
0x160E Not used 0 UINT32 R
0x160F kW import accumulated demand 0-Pmax U3 UINT32 R
0x1610 kvar import accumulated demand 0-Pmax U3 UINT32 R
0x1611 kVA accumulated demand 0-Pmax U3 UINT32 R
0x1612 kW import predicted sliding window demand 0-Pmax U3 UINT32 R
0x1613 kvar import predicted sliding window demand 0-Pmax U3 UINT32 R
0x1614 kVA predicted sliding window demand 0-Pmax U3 UINT32 R
0x1615 PF (import) at Max. kVA sliding window demand 0-1000
×0.001
UINT16 R
0x1616 kW export block demand 0-Pmax U3 UINT32 R
0x1617 kvar export block demand 0-Pmax U3 UINT32 R
0x1618 kW export sliding window demand 0-Pmax U3 UINT32 R
0x1619 kvar export sliding window demand 0-Pmax U3 UINT32 R
0x161A kW export accumulated demand 0-Pmax U3 UINT32 R
0x161B kvar export accumulated demand 0-Pmax U3 UINT32 R
0x161C kW export predicted sliding window demand 0-Pmax U3 UINT32 R
0x161D kvar export predicted sliding window demand 0-Pmax U3 UINT32 R
0x161E Not used UINT32 R
