Satec PM130P Reference Guide

20
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x6800
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6827
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
I3 Harmonic Angles
EH 3
0x6900
H01 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x6900
H02 Harmonic angle
-1800-1800
×0.1º
INT16 R
...
0x6927
H40 Harmonic angle
-1800-1800
×0.1º
INT16 R
0x7C00 Setpoint Status SP1-SP16 (bitmap) 0x00000000-0x0000FFFF UINT32 R
NOTES:
Energy and power demand readings are only available in the PM130E and PM130EH meters. Harmonics readings are only available in the PM130EH meters.
1
Voltage and voltage harmonics readings: when the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode, they will be line-to-line
voltages.
2
For volts, amps, power and frequency scales and units, refer to Section 4 ”Data Scales and Units”.
3
Harmonic angles are referenced to the fundamental voltage harmonic H01 on phase L1.
