Satec PM130P Reference Guide

17
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
V2/V23 Harmonic Distortions
EH 1
0x1A00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1A01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1A27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
V3/V31 Harmonic Distortions
EH 1
0x1B00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1B01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1B27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I1 Harmonic Distortions
EH
0x1C00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1C01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1C27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I2 Harmonic Distortions
EH
0x1D00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1D01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1D27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
I3 Harmonic Distortions
EH
0x1E00
H01 Harmonic distortion
0-10000 0.01% UINT16 R
0x1E01
H02 Harmonic distortion
0-10000 0.01% UINT16 R
...
0x1E27
H40 Harmonic distortion
0-10000 0.01% UINT16 R
Fundamental Phase Values
EH
2-cycle values
0x2900 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
0x2901 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
0x2902 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
0x2903 I1 Current 0-Imax U2 UINT32 R
0x2904 I2 Current 0-Imax U2 UINT32 R
0x2905 I3 Current 0-Imax U2 UINT32 R
0x2906 kW L1 -Pmax-Pmax U3 INT32 R
0x2907 kW L2 -Pmax-Pmax U3 INT32 R
0x2908 kW L3 -Pmax-Pmax U3 INT32 R
0x2909 kvar L1 -Pmax-Pmax U3 INT32 R
0x290A kvar L2 -Pmax-Pmax U3 INT32 R
0x290B kvar L3 -Pmax-Pmax U3 INT32 R
0x290C kVA L1 0-Pmax U3 UINT32 R
0x290D kVA L2 0-Pmax U3 UINT32 R
0x290E kVA L3 0-Pmax U3 UINT32 R
