Satec PM130P Reference Guide

26
Address Description Options/Range Units Type R/W Notes
+3 Baud rate COM1: 1=300 bps, 2=600 bps,
3=1200 bps, 4=2400 bps, 5=4800
bps, 6=9600 bps, 7=19200 bps,
8=38400 bps, 9=57600 bps,
10=115200 bps
COM2: 9=57600 bps
UINT16 R COM2 baud rate does not concern the
PROFIBUS baud rate
+4 Data format COM1: 0=7 bits/even parity,
1=8 bits/no parity,
2=8 bits/even parity
COM2: 1=8 bits/no parity
UINT16 R
+5 Flow control 0=no flow control UINT16 R N/A for COM1 (read as 65535)
+6 RTS mode 0=not used UINT16 R N/A for COM1 (read as 65535)
+7 ASCII compatibility mode 0=disabled, 1=enabled UINT16 R
+8-15 Reserved UINT16 R
0x8500-0x850F COM1 Setup
0x8510-0x851F COM2 Setup
Basic Setup
0x8600-0x8614
+0 Wiring mode F2 UINT16 R/W
+1 PT ratio 10 to 65000
×0.1
UINT16 R/W
+2 CT primary current 1 to 10,000 A UINT16 R/W
+3 Power block demand period
E
1,2,3,5,10,15,20,30,60 min,
255 = external synchronization
min UINT16 R/W If the external synchronization is selected, the
DI1 input is considered a pulse or KYZ input.
The pulse edge restarts the power demand
block accumulation interval.
E
+4 Volt/ampere demand period 0 to 1800 sec UINT16 R/W
+5-7 Reserved UINT16 R Read as 65535
+8 Number of blocks in a sliding window
E
1 to 15 UINT16 R/W
+9-10 Reserved UINT16 R Read as 65535
+11 Nominal line frequency 25, 50, 60, 400 Hz UINT16 R/W
+12 Maximum demand load current 0 to 10,000 (0 = CT primary
current)
A UINT16 R/W
+13-17 Reserved UINT16 R Read as 65535
+18 Nominal secondary voltage
E
10 to 690 V UINT16 R/W
+19 Reserved UINT16 R Read as 65535
+20 PT ratio multiplication factor
×1, ×10
UINT16 R/W
Device Options Setup
0x8700-0x870E
+0 Power calculation mode 0=using reactive power: S=f(P,Q),
1=using non-active power:
Q=f(S,P)
UINT16 R
+1 Energy roll value
E
0=1×10
4
, 1=1×10
5
, 2=1×10
6
,
3=1×10
7
, 4=1×10
8
, 5=1x10
9
UINT16 R
Provided by Northeast Power Systems, Inc.
www.nepsi.com
