18
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x290F Power factor L1 -1000-1000
×0.001
INT16 R
0x2910 Power factor L2 -1000-1000
×0.001
INT16 R
0x2911 Power factor L3 -1000-1000
×0.001
INT16 R
Fundamental Total Values
EH
2-cycle values
0x2A00 Total fundamental kW -Pmax-Pmax U3 INT32 R
0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT32 R
0x2A02 Total fundamental kVA 0-Pmax U3 UINT32 R
0x2A03 Total fundamental PF -1000-1000
×0.001
INT16 R
Minimum 1-Cycle Phase Values
0x2C00 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
0x2C01 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
0x2C02 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
0x2C03 I1 Current 0-Imax U2 UINT32 R
0x2C04 I2 Current 0-Imax U2 UINT32 R
0x2C05 I3 Current 0-Imax U2 UINT32 R
Minimum 1-Cycle Total Values
0x2D00 Total kW -Pmax-Pmax U3 INT32 R
0x2D01 Total kvar -Pmax-Pmax U3 INT32 R
0x2D02 Total kVA 0-Pmax U3 UINT32 R
0x2D03 Total PF 0-1000
×0.001
UINT32 R Absolute value
Minimum 1-Cycle Auxiliary Values
0x2E00 Not used UINT32 R
0x2E01 In Current 0-Imax U2 UINT32 R
0x2E02 Frequency 0-Fmax
×0.01Hz
UINT32 R
Maximum 1-Cycle Phase Values
0x3400 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
0x3401 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
0x3402 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
0x3403 I1 Current 0-Imax U2 UINT32 R
0x3404 I2 Current 0-Imax U2 UINT32 R
0x3405 I3 Current 0-Imax U2 UINT32 R
Maximum 1-Cycle Total Values
0x3500 Total kW -Pmax-Pmax U3 INT32 R
0x3501 Total kvar -Pmax-Pmax U3 INT32 R
0x3502 Total kVA 0-Pmax U3 UINT32 R
0x3503 Total PF 0-1000
×0.001
UINT32 R Absolute value
Maximum 1-Cycle Auxiliary Values
0x3600 Not used UINT32 R
0x3601 In Current 0-Imax U2 UINT32 R
0x3602 Frequency 0-Fmax
×0.01Hz
UINT32 R
Maximum Demands
0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT32 R
1
0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT32 R
1
