13
Point ID Description
Options/Range
2
Units
2
Type R/W Notes
0x0C1B I1 Current TDD 0-1000
×0.1%
UINT16 R 2-cycle value
0x0C1C I2 Current TDD 0-1000
×0.1%
UINT16 R 2-cycle value
0x0C1D I3 Current TDD 0-1000
×0.1%
UINT16 R 2-cycle value
0x0C1E V12 Voltage 0-Vmax U1 UINT16 R
0x0C1F V23 Voltage 0-Vmax U1 UINT16 R
0x0C20 V31 Voltage 0-Vmax U1 UINT16 R
1-Cycle Total Values
0x0F00 Total kW -Pmax-Pmax U3 INT32 R
0x0F01 Total kvar -Pmax-Pmax U3 INT32 R
0x0F02 Total kVA 0-Pmax U3 UINT32 R
0x0F03 Total PF -1000-1000
×0.001
INT16 R
0x0F04 Total PF lag 0-1000
×0.001
UINT16 R
0x0F05 Total PF lead 0-1000
×0.001
UINT16 R
0x0F06 Total kW import 0-Pmax U3 UINT32 R
0x0F07 Total kW export 0-Pmax U3 UINT32 R
0x0F08 Total kvar import 0-Pmax U3 UINT32 R
0x0F09 Total kvar export 0-Pmax U3 UINT32 R
0x0F0A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
0x0F0B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
0x0F0C 3-phase average current 0-Imax U2 UINT32 R
1-Cycle Auxiliary Values
0x1000 Not used UINT32 R
0x1001 In (neutral) Current 0-Imax U2 UINT32 R
0x1002 Frequency 0-Fmax
×0.01Hz
UINT16 R
0x1003 Voltage unbalance 0-3000
×0.1%
UINT16 R
0x1004 Current unbalance 0-3000
×0.1%
UINT16 R
Phasor
0x1080 V1/V12 Voltage magnitude 0-Vmax U1 UINT32 R
1
0x1081 V2/V23 Voltage magnitude 0-Vmax U1 UINT32 R
1
0x1082 V3/V31 Voltage magnitude 0-Vmax U1 UINT32 R
1
0x1083 Not used UINT32 R
0x1084 I1 Current magnitude 0-Imax U2 UINT32 R
0x1085 I2 Current magnitude 0-Imax U2 UINT32 R
0x1086 I3 Current magnitude 0-Imax U2 UINT32 R
0x1087 Not used UINT32 R
0x1088 V1/V12 Voltage angle -1800-1800
×0.1º
INT16 R
1
0x1089 V2/V23 Voltage angle -1800-1800
×0.1º
INT16 R
1
0x108A V3/V31 Voltage angle -1800-1800
×0.1º
INT16 R
1
0x108B Not used INT16 R
0x108C I1 Current angle -1800-1800
×0.1º
INT16 R
0x108D I2 Current angle -1800-1800
×0.1º
INT16 R
0x108E I3 Current angle -1800-1800
×0.1º
INT16 R
0x108F Not used INT16 R
