Satec PM130P User Manual

Chapter 4 Setup Menus 25
Table 4-5 Setpoint Triggers
(lower window, when middle window is triG)
Code Parameter Unit Range
nonE Setpoint disabled
Phase Reversal
POS.ro.
Positive phase rotation reversal 
NEG.ro.
Negative phase rotation reversal 
Real-time Values on any Phase
r. Hi. U
High voltage  V 0 to Vmax
r. Lo. U
Low voltage  V 0 to Vmax
r. Hi. C
High current A 0 to Imax
r. Lo. C
Low current A 0 to Imax
Real-time Auxiliary Measurements
r. Hi.Fr
High frequency  Hz 0 to 100.00
r. Lo.Fr
Low frequency  Hz 0 to 100.00
r. U.Unb
Voltage unbalance % 0 to 300
r. C.Unb
Current unbalance % 0 to 300
Average Values per Phase
A. Hi.C1
High current L1 A 0 to Imax
A. Hi.C2
High current L2 A 0 to Imax
A. Hi.C3
High current L3 A 0 to Imax
A. Lo.C1
Low current L1 A 0 to Imax
A. Lo.C2
Low current L2 A 0 to Imax
A. Lo.C3
Low current L3 A 0 to Imax
Average Values on any Phase
A. Hi. U
High voltage  V 0 to Vmax
A. Lo. U
Low voltage  V 0 to Vmax
A. Hi. C
High current A 0 to Imax
A. Lo. C
Low current A 0 to Imax
Average Total Values
A. Hi.P.i
High total kW import (positive) kW 0 to Pmax
A. Hi.P.E
High total kW export (negative) kW 0 to Pmax
A. Hi.q.i
High total kvar import (positive) kvar 0 to Pmax
A. Hi.q.E
High total kvar export (negative) kvar 0 to Pmax
A. Hi. S
High total kVA kVA 0 to Pmax
A. PF.LG
Low total PF Lag 0 to 1.000
A. PF.Ld
Low total PF Lead 0 to 1.000
Average Auxiliary Measurements
Ar neU.C
High neutral current A 0 to Imax
Ar Hi.Fr
High frequency  Hz 0 to 100.00
Ar Lo.Fr
Low frequency  Hz 0 to 100.00
Present Demands
Hi d.U1
High volt demand L1  V 0 to Vmax
Hi d.U2
High volt demand L2  V 0 to Vmax
Hi d.U3
High volt demand L3  V 0 to Vmax
Hi d.C1
High ampere demand L1 A 0 to Imax
Hi d.C2
High ampere demand L2 A 0 to Imax
Hi d.C3
High ampere demand L3 A 0 to Imax
P
E
P
E
P
E
P
E
P
E
P
E
