Appendix C Setpoint Triggers and Actions
PM135 Powermeter Series 151
Appendix C Setpoint Triggers and
Actions
Table 23: Setpoint Triggers
Display Code
Designation
Description
None
NONE
None (condition is not active)
Status Inputs
DI1 On
STAT INP #1 ON
Status input #1 ON
DI2 On
STAT INP #2 ON
Status input #2 ON
DI3 On
STAT INP #3 ON
Status input #3 ON
DI4 On
STAT INP #4 ON
Status input #4 ON
DI5 On
STAT INP #5 ON
Status input #5 ON
DI6 On
STAT INP #6 ON
Status input #6 ON
DI7 On
STAT INP #7 ON
Status input #7 ON
DI8 On
STAT INP #8 ON
Status input #8 ON
DI9 On
STAT INP #9 ON
Status input #9 ON
DI10 On
STAT INP #10 ON
Status input #10 ON
DI11 On
STAT INP #11 ON
Status input #11 ON
DI12 On
STAT INP #12 ON
Status input #12 ON
DI1 OFF
STAT INP #1 OFF
Status input #1 OFF
DI2 OFF
STAT INP #2 OFF
Status input #2 OFF
DI3 OFF
STAT INP #3 OFF
Status input #3 OFF
DI4 OFF
STAT INP #4 OFF
Status input #4 OFF
DI5 OFF
STAT INP #5 OFF
Status input #5 OFF
DI6 OFF
STAT INP #6 OFF
Status input #6 OFF
DI7 OFF
STAT INP #7 OFF
Status input #7 OFF
DI8 OFF
STAT INP #8 OFF
Status input #8 OFF
DI9 OFF
STAT INP #9 OFF
Status input #9 OFF
DI10 OFF
STAT INP #10 OFF
Status input #10 OFF
DI11 OFF
STAT INP #11 OFF
Status input #11 OFF
DI12 OFF
STAT INP #12 OFF
Status input #12 OFF
Relays
RO1 ON
RELAY #1 ON
Relay #1 ON
RO2 ON
RELAY #2 ON
Relay #2 ON
RO3 ON
RELAY #3 ON
Relay #3 ON
RO4 ON
RELAY #4 ON
Relay #4 ON
RO1 OFF
RELAY #1 OFF
Relay #1 OFF
RO2 OFF
RELAY #2 OFF
Relay #2 OFF
RO3 OFF
RELAY #3 OFF
Relay #3 OFF
RO4 OFF
RELAY #4 OFF
Relay #4 OFF
Phase Reversal
Pos Phase Reversal
POS PHASE
REVERSAL
Positive phase rotation reversal
Neg Phase Reversal
NEG PHASE
REVERSAL
Negative phase rotation reversal
Low/High 1-Cycle Values on any Phase
High Volt RT
HI VOLT RT
1
High voltage
Low Volt RT
LO VOLT RT
1
Low voltage
High Amps RT
HI AMPS RT
High current
Low Amps RT
LO AMPS RT
Low current
