Chapter 1 Introduction 3
Getting Started
Connect the Powermeter to a suitable power supply. The Powermeter
will initiate a series of self-tests. Upon completion of the self-tests, all of
the front panel LEDs will light up for one second and indicate a one-
digit diagnostic code. An ‘8’ represents normal power up. If a different
diagnostic code constantly appears when you apply power to the
instrument, contact your local distributor.
The Front Panel
• Select is used to enter the setup mode
from the default monitoring mode; it is also
used to define the setup parameters (see
Chapter 3, Initial Setup)
• Enter/Reset is used to
reset measured values (if in
monitoring mode) or to ente
setup parameter values (if in
setu
mode
• Up/Down arrow
keys are used to
scroll pages
forward/backward
