SATEL ETHM-1 Plus 19
0 - fully armed; 1 – fully armed+bypasses; 2 – armed without interior; 3 - armed without
interior and without entry delay).
Disarming – highlight the partitions which are to be disarmed (double-click on the field
designated by the partition number).
Alarm clearing – highlight the partitions in which alarm is to be cleared (double-click on
the field designated by the partition number).
Bypass zones – highlight the zones which are to be inhibited (double-click on the field
designated by the zone number).
Unbypass zones – highlight the zones which are to be unbypassed (double-click on the
field designated by the zone number).
Outputs ON – highlight the outputs which are to be activated (double-click on the field
designated by the output number).
Outputs OFF – highlight the outputs which are to be deactivated (double-click on the field
designated by the output number).
Change outputs state – highlight the outputs whose status is to be changed (double-click
on the field designated by the output number).
KNX telegram – program the following parameters of KNX telegram:
INT-KNX module – INT-KNX module which is to send the telegram.
Group address – the group address which will be inserted in the telegram.
Type – the telegram type.
Value – the value that will be inserted in the telegram (parameter available for some
types of the telegram).
Priority – telegram priority (if two elements of the bus start transmitting simultaneously,
the telegram with higher priority will be sent first).
KNX telegram (v2) – program the following parameters related to setting the value of KNX
communication object:
Module INT-KNX – INT-KNX-2 module in which the value is to be set.
Macro Command – name of the “Virtual (macro)” type object, defined in INT-KNX-2
module.
Data type – size and meaning of the communication object data defined in INT-KNX-2
module for selected object.
Value – value to be set (if the type of data provides for sending a sequence of
characters, you can enter up to 13 characters).
Exit delay clearing (no additional parameters to configure).
Quick arm – select the arming mode which is to be activated.
The partitions must be controlled by user code.
The zones must not have the BYPASS DISABLED option enabled.
The outputs must be the 24. MONO SWITCH, 25. BI SWITCH, 105. SHUTTER UP,
106. SHUTTER DOWN or REMOTE SWITCH type (they need not be assigned to any group
of outputs).
Using the INTEGRA CONTROL application, you can control the KNX system, if the
INT-KNX module is connected to the control panel.
