Unit 7: Appendix
SATO GL4xxe SBPL Programming Reference Page 7-3
4. To store the custom designed character in memory using a hexadecimal data stream:
<ESC>A
<ESC>T1H3F0100038007C00FE01FF03FF87FFCFFFE07C007C007C007C007C007C007C007C0<ESC>Z
5. To recall a custom character from memory, send the following code to the printer. Note the
character size was expanded using the <ESC>L command. Other data can also be printed.
<ESC>A
<ESC>L0505<ESC>H0150<ESC>V100<ESC>K1H903F
<ESC>L0505<ESC>H0600<ESC>V100<ESC>K1H903F
<ESC>L0303<ESC>H0125<ESC>V0250<ESC>MTHIS SIDE UP !
<ESC>Q1
<ESC>Z
6. To store the custom designed character in memory using a binary data stream:
<ESC>A
<ESC>T1B3F 01
H 00H 03H 80H 07H C0H 0FH E0H 1FH F0H 3FH F8H 7FH FCH FFH FEH 07H C0H 07H
C0H 07H C0H 07H C0H 07H C0H 07H C0H 07H C0H 07H C0H
<ESC>Z
7. To recall the custom character from memory, send the following code to the printer:
ROW BIT MAP HEX
1 0000 0001 0000 0000 01 00
2 0000 0011 1000 0000 03 80
3 0000 0111 1100 0000 07 C0
4 0000 1111 1110 0000 0F E0
5 0001 1111 1111 0000 1F F0
6 0011 1111 1111 1000 3F F8
7 0111 1111 1111 1100 7F FC
8 1111 1111 1111 1110 FF FE
9 0000 0111 1100 0000 07 C0
10 0000 0111 1100 0000 07 C0
11 0000 0111 1100 0000 07 C0
12 0000 0111 1100 0000 07 C0
13 0000 0111 1100 0000 07 C0
14 0000 0111 1100 0000 07 C0
15 0000 0111 1100 0000 07 C0
16 0000 0111 1100 0000 07 C0
NOTE: The data stream is only half as long as the hexadecimal format
because sending the binary equivalent of11111111 (represented above in
its hexadecimal value of FF
H), for example, using one eight bit word while it
takes two eight bit words to transmit the hexadecimal equivalent “F” and “F”.
To send binary characters using BASIC, the expression ìCHR (&HFF) will
send the binary equivalent of FF (i.e., 11111111).
