Unit 4: Standard Command Codes
SATO GL4xxe SBPL Programming Reference Page 4-45
DATA MATRIX CODE
FUNCTION
Specifies Data Matrix Code of 2D code.
FORMAT
<ESC>BXaabbccddeeeffffghh
a = Format ID (01 to 06 dots)
b = Error Correction Level
00: ECC000
05: ECC050
08: ECC080
10: ECC100
14: ECC140
20: ECC200
c = Cell Width (01 to 16 dots/cell)
d = Cell Pitch (01 to 16 dots/cell)
e = Number of Cells per Line (008 to 148)
000: Automatic)
f = Number of Cell Line (008 to 148)
000: Automatic
g = Mirror Image
0: Normal Image (standard print)
1: Mirror Image
h = Guide Cell Size (01 to 15)
Place anywhere after <ESC>V but before <ESC>Q.
EXAMPLE
<ESC>V0100<ESC>H0100
<ESC>BX05051010000000001
<ESC>DCDATA MATRIX DATA MATRIX
OUTPUT
(4-33)
NOTES
If “20” is specified for Error Correction Level, the specification of Format ID, Mirror
Image, and Size of Guide Cell will be ignored.
“01” and “02” are designable for Cell Width and Cell Pitch; however, they may not
read properly. In this case, “00” will be an error.
If “000” is specified for Number of Cells per Line and Number of Cell Lines, optimum
matrix size is automatically set based on the number of data.
The thickness of normal type guide cell is “01”.
Refer to Appendix: Reference Table 28 for additional information.
