SATO GL 4xxe Series Programming Reference Guide

Unit 4: Standard Command Codes
SATO GL4xxe SBPL Programming Reference Page 4-19
JOURNAL PRINTING
FUNCTION
To print text in a line by line format on a label. By specifying this command, you
automatically select Font XS with a Character Expansion of 2x2. You also establish a
base reference point of H2,V2. The character pitch is 2 dots and the line gap is 16
dots. Simply issue an ASCII <CR> at the end of each text line.
FORMAT
<ESC>J
Place immediately following <ESC>A.
EXAMPLE
<ESC>A
<ESC>J WITH THE JOURNAL FEATURE YOU CAN PRINT TEXT WITHOUT
USING ANY FONT COMMANDS
OR POSITION COMMANDS
<ESC>Q1
<ESC>Z
OUTPUT
(4-14)
NOTES
Journal mode assumes a maximum label width. Otherwise, you may print where
there is no label and damage your print head.
It is effective only for the current print job.
