Unit 4: Standard Command Codes
SATO GL4xxe SBPL Programming Reference Page 4-44
MAXI CODE
FUNCTION
Specifies Maxi code of 2D code.
FORMAT
<ESC>BVa, b, c, ddddddddd, eee, fff, n~n
a = Symbol Number (1 to 8)
b = Symbol Digit Number (1 to 8)
c=Mode
2: for delivery
3: for delivery
4: standard symbol
6: for reader
d = Zip Code (0 to 999999)
e = Country Code (001 to 999)
f = Service Class (001 to 999)
n = Low Priority Message (alphanumeric/symbol)
Place anywhere after <ESC>V but before <ESC>Q.
EXAMPLE
<ESC>A<ESC>V0100<ESC>H0100
<ESC>BV1,1,2,123456789,840,001,[)<RS>01<GS>961Z01547089<GS>UPSN
<GS>056872<GS>348<GS>99999999<GS>001/005
<GS>029<GS>N<GS><GS>LENEXA<GS>KS<RS><EOT>
<ESC>Q1
<ESC>Z
OUTPUT
(4-32)
NOTES
For mode 2, specify up to 9 numeric digits; and for mode 3, specify fixed 6 digits
(alphanumeric - use English capital letters). “00H” cannot be specified for print data.
