Unit 3: Command Quick Reference
SATO GL4xxe SBPL Programming Reference Page 3-2
COMMAND QUICK REFERENCE
INSTRUCTION DESCRIPTION
A Start Code. Begins all print jobs
~Aaaaa Cut, Label. Specifies the number of labels to print between each cut. It is
independent of the Quantity command.
aaaa = Number of labels between each cut
~aaaa Cut, Job. Cuts labels at a specified interval in a print job. Quantity of labels
printed is equal to the product of the quantity specified x the value of aaaa.
aaaa = Number of labels between each cut (0001 to 9999)
~B Cut, Last. Cuts any printed labels that remain in the printer.
AOa Auto Online. Allows the automatic online on power up setting to be
enabled or disabled.
a = 0: Powers up in the online mode
1: Powers up in the offline mode
A1aaaabbbb Media Size. Specifies the label size.
aaaa = Label height in dots (0 to Vmax)
bbbb = Label width in dots (0 to Hmax)
& Store Form Overlay. Stores a specified label image in the printer’s volatile
form overlay memory.
AR Normal Print Length. This command resets the printer to the Standard
print length (7 inches).
&Raa Form Overlay, Recall. Recalls a label image previously stored in
Expanded Memory.
aa = Storage number (00 to 99)
&S,aa,bbbb,cccc Form Overlay, Store. Stores a label image in Expanded Memory.
aa = Storage number (00 to 99)
bbbb = Horizontal size of window to be stored (50 to Hmax)
cccc = Vertical size of window to be stored (50 to Vmax)
