SATO GL 4xxe Series Programming Reference Guide

Unit 3: Command Quick Reference
SATO GL4xxe SBPL Programming Reference Page 3-10
$ Font, Vector. Specifies printing of the unique SATO vector font.
a = A: Helvetica Bold (proportional spacing)
B: Helvetica Bold (fixed spacing)
b = Font width (50 to 999 dots)
c = Font height (50 to 999 dots)
d = Font variation (0 to 9) as follows:
0: Standard
1: Standard open (outlined)
2: Gray (mesh) pattern 1
3: Gray (mesh) pattern 2
4: Gray (mesh) pattern 3
5: Standard, shadow 1
6: Standard, shadow 2
7: Standard mirror image
8: Italic
9: Italic open (outlined)
$= Outline Font Print. Specifies the print of outline font.
n=Print data
Eaaa Line Feed. Provides the ability to print multiple lines of the same character
size without specifying a new print position for each line.
aaa = Number of dots (1 to 999) between the bottom of the
characters on one line to the top of the characters on the
next line.
EP Print End Position. Specifies the label stop position in the sensor valid
mode.
EU EAN/UCC Composite Symbol. Specifies the composite symbol of EAN/
UCC.
EX0 Expanded Print Length. Expands the print length to 9999 dots.
Faaaabcccc ddee Sequential Numbering. Allows the printing of sequencing fields (text, bar
codes) where all incrementing is done within the printer.
aaaa = Number of times to repeat the same data (0001 to 9999).
b = Plus or minus symbol (+ for increments; - for decrements).
cccc = Value of step for sequence (001 to 9999).
dd = Quantity of digits for sequential numbering (01 to 99).
ee = Quantity of digits free for sequential numbering (01 to 99).
COMMAND QUICK REFERENCE
INSTRUCTION DESCRIPTION
