28
SA408 - Userā€™s Manual
5. Install the other ribbon roll and rotate it until the notches align and
lock into the left side of Ribbon Pick-up hub, and then the right.
Ribbon
Pick-up
Holder
Note:
The Ribbon Pick-up Holder accepts the coated side of ribbon to
be wound ink-side OUT only.
