SATO SA408 - Page 29

29
SA408 - User’s Manual
6. Close the printer module and then press firmly at the both sides to
properly latch it until you hear a click.
7. Rotate Thumb Wheel of Ribbon Pick-up Holder to remove slack
and ribbon wrinkle, and to align the ribbon on the spindles.
Thumb Wheel
