Maintenance
WP33L_BA_K1_12_en_08.fm
57
8.7 Air Intake filter cartridge cleaning
1. Loosen clamp and remove air filter.
2. Unfasten the clips at the air filter and remove air filter cap.
3. Wipe out the cover with a lint-free cloth.
4. The air filter is part of the base of the air filter cage. Wash out
the air filter with an oil dissolving fluid (e.g. kerosine).
5. Blow out the air filter with compresed air from inside to out-
side.
6. Replace cap and mount the air filter on the cylinder head.
Danger!
Do not train compressed air on persons!
Note!
The air filter has to be replaced, if cleaning is not possible.
