Sauer WP 33 L - Separator and Safety Valves

Maintenance
WP33L_BA_K1_12_en_08.fm
71
8.16 Checking the oil/water separator
1. Kompressor ausser Betrieb setzen und gegen Wiederanlauf
sichern.
2. Angebaute Leitungen und Schläuche demontieren.
3. Remove safety valve 2
nd
stage.
4. Remove separator housing from the crankcase.
5. Remove reducing stub from the separator.
6. Take out the sieve and check it.
7. Blow out the sieve with air.
8. Check the separator for damage..
9. Clean the separator housing with kerosene.
10. Blow out kerosene with air.
11. Assembly follows the steps in reverse order.
Item Designation
1 Separator, separator housing
2
Safety valve 2
nd
stage
3 Reducing stub
2
1
3
