sauter ASV3 - Page 40

Page 40 of 45
BACNET
OBJECT
ID
BACNET OBJECT NAME
READ/
WRITE
MODBUS
ID
NOTE
BV24
Heating icon
No =0,Yes=1
0
R
C24
(HMI)
-
BV25
Fan Icon
No =0,Yes=1
0
RW
C25
(HMI)
-
BV26
Sleep Icon
No =0,Yes=1
0
RW
C26
(HMI)
-
BV27
Unoccupied
Icon
No =0,Yes=1
0
R
C27
(HMI)
-
BV28
Tool Icon
No =0,Yes=1
0
RW
C28
(HMI)
-
BV29
Sending /
Calculating
Icon
No =0,Yes=1
0
R
C29
(HMI)
-
BV30
ON/OFF icon
No =0,Yes=1
0
R
C30
(HMI)
-
BV31
Button
pressed
(alarm reset)
No =0,Yes=1
-
-
C31
(HMI)
-
BV32
ON/OFF
control status
Off =0, On=1
-
RW
C32
(HMI)
-
BV33
ON/OFF is
allow ed
Allow =0, Prohibit=1
0
R
C33
(HMI)
-
BV34
HMI
Temperature
setting is
allow ed
Allow =0, Prohibit=1
0
R
C34
(HMI)
-
BV35
BV-35
HMI humidity setting is
allow ed, Allow =0,
Prohibit=1
0
RW
C35
(HMI)
For EY-
RU305F7002W
BV36
BV-36
HMI CO2 setting is allow
ed, Allow=0, Prohibit=1
0
RW
C36
(HMI)
For EY-
RU305F7003W
BV37
BV-37
HMI pressure setting is
allow ed, Allow
=0,Prohibit=1
0
RW
C37
(HMI)
-
BV38
Deg C/F Unit
display select
DegC=0,DegF=1
0
RW
C38
(HMI)
-
BV39
Deg/Pa
display select
Deg=0, Pa=1
0
RW
C39
(HMI)
-
BV40
24hr/12hr
time mode
select
24 hr=0,12 hr=1
0
RW
C40
(HMI)
-
BV41
Humidity
display
No =0,Yes=1
0
R
C41
(HMI)
For EY-
RU305F7002W
BV42
ID address
display
No =0,Yes=1
0
RW
C42
(HMI)
-
