BACNET
OBJECT
ID
BACNET OBJECT NAME
READ/
WRITE
MODBUS
ID
NOTE
BV43
Clock display
No =0,Yes=1
0
RW
C43
(HMI)
-
BV44
PPM display
No =0,Yes=1
0
R
C44
(HMI)
For EY-
RU305F7003W
BV45
RPM display
No =0,Yes=1
0
RW
C45
(HMI)
-
BV46
BV-46
Internal Use
-
-
C46
-
BV47
BV-47
Internal Use
-
-
C47
-
BV48
BV-48
Internal Use
-
-
C48
-
BV49
CO2 control
0=ai1 co2 sensor, 1=HMI
co2 sensor
0
-
C49
-
BV50
BV-50
Internal Use
-
-
C50
-
BV51
VAV/CAV
mode select
0=VAV,1=CAV
0
-
C51
-
BV52
BV-52
Arithmetic Operation-Off
delay 160 sec after BV55
-
-
C52
-
BV53
BV-53
Arithmetic Operation-
BV104 &
!BV52
-
-
C53
-
BV54
BV-54
Arithmetic Operation-
AV113 is within
AV122~AV123
-
-
C54
-
BV55
BV-55
Arithmetic Operation- On
delay 5sec after BO54
-
-
C55
-
BV56
BV-56
Arithmetic Operation-
BV62 & BV38
-
-
C56
-
BV57
BV-57
Arithmetic Operation-
AV33 changes>.1
-
-
C57
-
BV58
BV-58
Arithmetic Operation-
AV34 changes>.1
-
-
C58
-
BV59
Pow er off
min
open/min f
low select
0 min VAV open position,1
Vmin
0
-
C59
-
BV60
Ai1control
mode
disable/
enable 0-
10VDC
0 Disable,1 Enable.
0
-
C60
-
BV61
BV-61
Arithmetic Operation-
AV35 changes>.1
-
-
C61
-
