009-1839-04 | Savant IP Audio Products with Integrated Host Deployment Guide 45 Perseverance Way, Hyannis, MA 02601
200207 | © 2020 Savant Systems, LLC
7 of 25
Savant.com | 508.683.2500
3.5. WiSA
The HST-STUDIO55WS-SUR is WiSA certified. The WiSA setup is done inside the Savant Pro App, for more information on WiSA setup see the
Savant WiSA Setup Guide on the Savant Customer Community.
3.6. Power
The IP Audio Products have an AC Power connection.
SURGE PROTECTION!
Use a surge-protected circuit for all components and power supplies requiring 100/240V (AC 50/60 Hz) source power.
ELECTRICAL DISCONNECT!
The source power outlet and power supply input power sockets should be easily accessible, to disconnect power in the event of an electrical
hazard or malfunction.
3.7. Checking and Replacing the Fuse
To check or replace the HST-SIPA1SM-xx fuse, carefully follow the instructions below:
ELECTRIC SHOCK HAZARD:
This device must be disconnected from AC power by removing the power cord from the AC outlet and the unit before checking or replacing
the fuse.
1. Disconnect the unit from AC power by removing the power cord.
2. Remove the fuse cartridge by pulling the tab marked
A
in the image below.
3. Remove the old fuse from the cartridge and discard.
4. Gently clip the new fuse into the cartridge and slide the cartridge part way into the receptacle, ensuring that the alignment is correct.
5. Press cartridge fully into receptacle, ensuring that it is seated and secure.
A
NOTE: If any resistance is encountered while seating the cartridge, DO NOT apply more pressure. Stop pressing the cartridge, remove it, verify that
the fuse is properly placed and fully seated, align cartridge carefully, and reinsert.
