Manual Manual PCD 1 / PCD 2 Series │ Document 26 / 737 EN22 │ 2013-11-26

Input/output (I/O) modules

5-105

Analogue I/O modules

5.15 Analogue thermocouple modules

PCD2.W745 4-channel thermocouple modules for J, K … thermoelemets

Supported temperature sensors are:

●  Thermocouples – TC type J, K

●  Resistive temperature detectors – RTD’s type Pt 100, Pt 1000, Ni 100, Ni 1000

I/O modules and I/O terminal blocks may only be plugged in and removed when the

Saia PCD

and the external +24 V are disconnected from the power supply.

The module PCD2.W745 is described in the manual 26/796.
