[Capacitance measurement]
Measurement Range can be selected for Auto Range or Manual Range.
Range: 5㎋
, 50㎋, 500㎋, 5㎌, 50㎌, 500㎌ (6 ranges)
Count : 5,000 counts
Measured value is displayed on the main display along with Bar-Graph display.
Sub Menu selectable : Min/Max, Relative, Limit
[N
OTE]
When measuring high capacity capacitance values, discharge the capacitors and select an
appropriate measurement range to save measurement time and to get accurate
measurement values.
When measuring low capacity capacitance values, short the test leads and press “Relative”
to remove any residue Capacitance on Test Lead/Probes.
AUX Measurements
Meter can measure Temperature, Currents, Relative Humidity and Pressure by connecting
external Probes. Bar-Graph can be Bi-Directional or Single Directional depending on Mode.
Temperature,& DC Amps are Bi- Directional with negative scale left of “0” point.
Humidity, Pressure, & AC Amps are single directions with scale to right of “0” point.
