SBS 600 - Calibration Procedure Steps; DC Voltage Specifications

52
 Calibration procedure
Meter Calibration procedure is as follows;
①
Hold “USER” Mode key longer than 2 seconds to enter the User Menu.
②
Select “Calibration” in Menu.
③ Select Calibration function to calibrate (DC/V, AC/V, DC/A, AC/A, Resistance, etc.)
④ Connect reference Signal from the Calibrator to the Meter and observe the display.
⑤ Press “Start” key on the Meter.
⑥ While adjustment is in progress, the right upper screen shows the symbol "CAL". If the value
is within the allowable range, "PASS” will come up momentarily and Calibrator advances to
the next calibration item. If the value is out of the allowable range, Error Code is display for 3
seconds and the unit remains at the present calibration step. In this case, check the input
value was correctly applied.
⑦ To continue calibration of the other functions, select other calibration item and repeat the
above steps of the procedure.
⑧ When all of the functions are calibrated, press “Enter” key to complete Calibration process.
⑨ Power the meter first “Off” and then “On”. Then return to normal measurement mode.
7. Specifications
 Electrical Specifications
 DC Voltage
 Start measurement after minimum 1 minute warm up time.
 DC Accuracy ± (Reading % + LSD)
Function
Range
Resolution
Accuracy
DC Voltage
50.000㎷
0.001㎷
0.05+50
500.00㎷
0.01㎷
0.025+10
5.0000V
0.0001V
0.025+10
50.000V
0.001V
0.025+10
500.00V
0.01V
0.030+10
1000.0V
0.1V
0.030+10
 DC Currents
Function
Range
Resolution
Accuracy
DC Current
500.00㎶
0.01㎂
0.05+10
5.0000㎃
0.0001㎃
0.05+10
50.000㎃
0.001㎃
0.15+10
500.00㎃
0.01㎃
0.15+10
10.000A
0.001A
0.30+10
