Help
Press the (Help) key will bring up brief Information about the active Function on the
display.
Help Information pages cam be scrolled up/down with ▼▲ keys.
Select the Help Language after pressing the key.
Battery Save
This mode minimizes Battery power consumption during long duration use of meter in Data
Logging mode. When Battery Save mode is activated, all functions including Display and any
features not related to Data Logging are shut off. Battery save function starts 10 minutes
after Data Logging begins, to see the Display, press the key.
When Battery Save mode is active, Auto Power Off function is disabled.
5. Maintenance
This chapter explains the basic maintenance of the meter.
General Maintenance
Battery Replacement
Battery Charging
Fuse Replacement
[Note]
Troubleshooting beyond that specified in this manual is only to be completed by an
authorized repair center.
General Maintenance
Wet or Dusty Input Terminals could cause incorrect measurement readings.
Cleaning procedure is as follows.
① Power off the Meter and remove the Test Leads/Probes from the Meter.
② Turn the meter face down and remove any dust in the terminals by gently shaking the
meter.
③ Clean the Exterior Cases with soft detergent or wet cloth. Do not use Solvents or any
abrasive cleaning agents.
④ Clean cotton swab wet with Alcohol may be used to clean out the surface of the Input
Terminals.
Battery Replacement
[Note]
When Battery low signal is blinking, replace the batteries as soon as possible.
If Battery is completely drained replace the Batteries using the following procedure.
① Remove the Protective Holster Case from the Meter.
② Remove the Battery Cover from the Rear Case of the meter.
③ Replace Batteries and ensure to connect the correct polarity inside the battery
compartment.
④ Close the Battery Cover and re-assemble in the reverse order as above.
