3. MEASUREMENT SECONDARY FUNCTIONS
Data Logger
Data Logger Set Up
Start Recording Start
Recording Stop
Recall
Zoom
Data Save, Recall, Erase
Hold(Data Hold, Auto Hold)
㏈m Display
USB PC Communication
Relative measurement
Peak Detect
Limit
Max/Min
Data Logger
The meters data logging function can collect measured data and save the results for
diagnosing trends and events over long periods of time. The logging feature works on
Voltages, Currents, Resistance, Capacitance and AUX measurements (Temperature, High
Currents, Relative Humidity and Pressure)
Measured data is saved in the internal memory of meter which is stored even if the Data
Logger is power off or the battery is replaced. While Data logging, the data includes Min.
Max, Average data and the logged data records can be recalled on the meter display through
the Recall function or on the PC through PC interface software program.
Logged Data includes Logging Time information which consists of Sampling Time, Min/Max
value detection time, logged data is accumulated from Start to Stop.
The Data Logging function has a 3 step menu, Logging Setup Menu, Active Logging Menu,
and Logging Review Menu.
[Menu – Logging Setup]
