 When Capacitance value is below 5㎋, use “Relative” function to make accurate measurement.
 Square Waveform Signal Out
Output
Range
Resolution
Accuracy
Frequency
10㎐
0.001㎐
0.005%
100㎐
0.01㎐0.005%
1㎑
0.1㎐0.005%
10㎑
〈2㎐0.005%
100㎑
〈170㎐0.005%
1000㎑
〈16㎑0.005%
Duty Cycle
5~95%
0.1%〈60㎑
1%〈600㎑
±0.5%
Amplitude
Fixed(5.0V)
0.1V
±0.2V
 Out Put Impedance: Max 3.5kΩ.
 Out Put Frequency accuracy is different from Signal Frequency
 Duty Cycle and Pulse Width Accuracy is based on 5V Square wave without Signal divide.
 Measurement Rate per function
Function
Measurement Rate
AC V
7/s
DC V
7/s
AC+DC V
2/s
Ω
14/s
Diode
14/s
Capacitance
4 (< 10μF)/s
DC A
7/s
AC A
7/s
AC+DC A
2/s
[Input Impedance]
Function
Range
Input Impedance
DC Voltage
50.000㎷
10.00MΩ
500.00㎷
10.00MΩ
5.0000V
11.10MΩ
50.000V
10.10MΩ
500.00V
10.01MΩ
1000.0V
10.001MΩ
AC Voltage
50.000㎷
10.00MΩ
500.00㎷
10.00MΩ
5.0000V
11.10MΩ
50.000V
10.10MΩ
500.00V
10.01MΩ
1000.0V
10.001MΩ
