SBS-6500 User Manual
Storage Battery Systems, LLC.
6.1. Data Base Entries
[Information that is stored in the DB entry]
 DB No (???/200) Up to 200 reference values can be programmed and stored.
 Battery Voltage Nominal voltage of the cell measurement interval.
 Capacity Rated AH capacity of that battery model
 Impedance Reference impedance values for that battery model
 Model Number Specific model of battery or cell
 Maker Manufacturer’s name for reference
6.2. Data Base Functionality
 Prior to measurement, recall one of the reference data entries saved in the DB and use
as battery comparison information for testing.
 Use the limit feature on the measurement screen to select the desired reference value
from the DB, press RECALL key to automatically open the DB mode and select
the desired DB entry as reference data by using keys. This changes the
alarm thresholds to the new reference value.
 The selected DB entry battery information is used in the generation of reports and
history of measurements for that string of batteries.
6.3. Entry and Deletion of DB Entries
Input, editing or deletion of DB entries can be done directly on the SBS-6500 or through
the SBS Battery Link PC Program.
[Input a New DB Entry]
 Press key to enter data display screen.
 Press key to select DB. Press to enter DB mode.
 Use key to scroll through the reference entries to the next blank entry.
 Press key to open the new DB entry page display screen.
