7.5. Recording Address Selection.
[Address Set-Up Procedure]
① Press the key to enter data display screen.
② Press key to select RECORD then press to enter.
③ Select string and address by direction keys or encoder switch.
④ After selection of the string, the data table for that string will open up. Move the
cursor to the location you want to record your readings and press the
key to complete the settings and return to resistance measuring mode. When operating
in auto record mode, the data will automatically recorded in the next open test number
slot.
[NOTE]
When recording, please follow the above procedure.
If the selected address already contains data, it will ask whether to use the next
address or overwrite the data already existing in that address.
If readings are taken without selecting an address, the data readings are recorded in
the temporary address (000) which operates in auto record. These readings can be
copied to a permanent location at a later date and time.
